链号	节距 Pitch p mm	梯级距	内链节内宽 Inner width of inner link b1(min) mm	滚轮直径 Roller diameter d1(max) mm	销轴直径 Pin diameter d2(max) mm	销轴长度 Pin length b2 mm	梯级销轴 Step pin		链板高度 Plate height h2 mm	拉伸载荷 Tensile load min KN	重量
							直径 diameter	伸出长
T133A	133.33	400±0.2	27min	φ76	φ14.63	55.2	φ14.63	31	41	130	0.86
T133B	133.33	400±0.2	27min	φ76	φ14.63	55.2	φ14.63	31	40	180	0.82
T133C	133.33	400±0.2	27min	φ76	φ24	56	φ20	36	50.6	180	1.26
T133D	133.33	400±0.2	27min	φ76	φ14.63	55.2	φ14.63	31	40	180	0.77
T133E	133.33	400±0.2	27min	φ76	φ14.63	55.2	φ14.63	31	40	130	0.77
T133F	133.33	400±0.2	27min	φ76	φ12.67	51	φ12.67	31	40	90	0.48
T133G	133.33	400±0.2	27min	φ75	φ14.63	55.2	φ14.63	31	40	180	0.83
T133H	133.33	400±0.2	27.1min	φ80	φ24	56	φ20	31	50.6	200	1.14
T133I	133.33	266.66±0.2	27.1min	φ80	φ24	56	φ20	31	50.6	200	1.19
T133J	133.33	400±0.2	32.9min	φ90	φ29	68	φ20	31	60	310	1.7
T133K	133.33	400±0.2	25.1min	φ75	φ12.5	49	φ12.8	28.5	35	88	0.64
T133L	133.33	400±0.2	25.2min	φ75	φ14.63	53.4	φ14.8	33.5	35	150	0.77
T133M	133.33	399.99+0.2 -0.1	25.1min	φ75	φ20	49	φ20	34.5	45	173	0.82
T133N	133.33	400±0.2	27min	φ70	φ14.63	55.2	φ14.63	31	40	180	0.81
T133O	133.33	399.99+0.23 -0.17(2外1内) 399.99+0.37 -0.03(2内1外)	35.5min	φ70	φ12	58.5	φ14.63	31	35	120	0.67
T133P	133.33	400±0.2	25min	/	φ20	51	/	/	45	120	0.82
T133Q	133.33	400±0.2	30min	φ110	φ17.5	60.5	/	/	40	180	1.16
T133R	133.33	400+0.2 -0.1	25.1min	φ75	φ12.5	48.4	φ12.8	28.5	35	105	0.67
T133S	133.33	400±0.2	27.1min	φ70	φ14.63	55	φ14.63	31	35	150	0.75
T133T	133.33	400±0.2	27min	φ70	φ14.63	55.2	φ14.63	31	35	123	0.73
T133U	133.33	400+0.2 -0.1	21min	φ75	φ12.6	47	φ12.8	32.5	32	105	0.7
T135V	135	405±0.2	27.3min	φ75	φ14.63	54	φ15	65	32	120	/
T135W	135	405±0.2	27.3min	φ75	φ14.63	54	φ15	65	40	190	/
T135X	135	405±0.2	27.3min	φ75	φ20	55	φ15	51.5	43/46	190	/
